Reliable Fire Safety Solution: PROCURAL EI30 Glass Systems

In modern architecture, fire safety is just as important as aesthetics. PROCURAL EI30 fire-resistant aluminum and glass systems offer both visual appeal and vital protection in buildings with high foot traffic, such as shopping malls, hospitals, schools, public institutions, and commercial spaces.

What is EI30?

EI30 is a European fire-resistance classification defined by the EN 13501-2 standard. It reflects how long a building element can resist fire and includes two key components:

• E – Integrity: Prevents the passage of flames, smoke, and hot gases for 30 minutes.

• I – Insulation: Limits the heat transfer caused by fire to the non-fire side for 30 minutes. This is crucial for safe evacuation and for preventing secondary ignition.

What Does an EI30 Fire-Rated System Offer?

• Essential protection during the first 30 minutes of a fire.

• Full compliance with fire safety regulations.

• Time for safe evacuation, reduced panic risk.

• Recommended or required in public and commercial buildings.

PROCURAL EI30 Product Range

✅ PROCURAL PE78EI EI30 – Fire-Rated Window System

• Frame/Sash Depth: 78 mm

• Glazing Thickness: 39–42 mm insulated glass units

• Standards: EN 1279-1, EN 1279-5

• Certification: ITB-KOT-2017/0351

• Provides secure and transparent openings within interiors.

✅ PROCURAL PE78EI EI30 – Butt-Jointed Glass Partition

• Frame Depth: 78 mm

• Glazing: 21–23 mm fire-resistant glass

• Certificates: ITB-KOT-2017/0351, ITB-KOT-2018/0529

• Ideal for minimalist partitions with maximum fire protection.

✅ PROCURAL PF152EI EI30 – Curtain Wall System

• Vertical/Horizontal Profiles: 52 mm width

• Infill Options: 15–66 mm glass or opaque panels

• Compatibility: Works with PE78EI window and door systems

• Enables safe, seamless fire-resistant façades in high-rise structures.

✅ PROCURAL PF152ESG EI30 – Fire-Rated Glass Roof System

• Rafter Depth: 85–196 mm

• Beam Depth: 91–201 mm

• Infill: 37–75 mm insulated glass or opaque panels

• Fire Classification: REI30 / RE45

• Designed specifically for safe and stylish glazed roof areas.

Why Choose PROCURAL EI30 Fire-Resistant Glass Systems?

• Certified with National Technical Assessments and EN Standards

• Maintains structural integrity and user safety during fire

• Blends safety with architectural elegance

• Offers custom solutions for residential, commercial, and public buildings

Need Help Choosing the Right Fire-Resistant System?

Every project is unique. Contact us to get detailed information about the most suitable EI30 fire-resistant glass systems for your building. Our team will help you find the perfect solution for optimal safety and aesthetics.
